Maximize Engine Performance with the BC-X15Q60 CUMMINS HPI Actuator Test Bench

Maximize Engine Performance with the BC-X15Q60 CUMMINS HPI Actuator Test Bench

If you are dealing with heavy-duty diesel engines, you know that the precision of the fuel injection system is critical. For diesel mechanics and remanufacturing facilities, the BC-X15Q60 Actuator Test Bench is a game-changer. Designed specifically as a CUMMINS HPI ISX ISX15 QSX15 QSK60 Engine Diesel Fuel Pump Metering Control Timing Actuator Tester Test Bench, this equipment ensures your injectors and actuators are operating at peak factory specifications.

What is the BC-X15Q60 Test Bench?

Manufactured by Beacon Machine, the BC-X15Q60 is professional diagnostic equipment mainly used to test the flow and pressure of HPI actuators. Whether you are dealing with metering control or timing actuators for Cummins ISX or massive QSK60 series engines, this test bench provides highly accurate data to diagnose faults and calibrate components.

Core Features

• Comprehensive Testing: Independently tests both the metering and timing functions of the HPI actuator.

• Intuitive System Interface: Equipped with a user-friendly digital system (as shown in the user manual) that displays real-time drive curves, inductance, and response times for precise adjustments.

• Flexible Power Options: Supports multiple power configurations including 380V 3-phase, 220V 3-phase, and 220V single-phase to suit different workshop environments.

• High Precision: Offers strict fuel pressure control (0-24bar) with a control accuracy of 1bar.


Technical Parameters

• Voltage Control Range: Phase adjustment

• Frequency Control: 0-65535us

• Time Control: 0-1000 times

• Delivery Oil Count Control Accuracy: 1 times

• Fuel Pressure Control: 0-24bar (Accuracy: 1bar)

• Product Size: 140 * 85 * 180 cm

• Weight: 300 KG

Maintenance & Safety Recommendations

To ensure the longevity of the equipment, operators should ensure reliable grounding. Use an independent dedicated socket, and if the local power supply is unstable, a power regulator is highly recommended. Regular maintenance, such as changing the fuel tank oil every 400 hours and checking the AC power cord, will keep your bench running smoothly.

(Contact Beacon Machine Manufacturing Co., Ltd. for the complete maintenance cycle details and software updates.)

6.Application Scenarios & FAQ

Application Scenarios

• Diesel Engine Repair Workshops: Essential for workshops diagnosing and fixing misfires, low power, or rough idling issues on Cummins ISX/QSX/QSK powered trucks and heavy machinery.

• Fuel Injection Remanufacturing Centers: Used to calibrate and verify rebuilt HPI metering and timing actuators before they are sent back to customers.

• Mining & Marine Maintenance Facilities: The QSK60 is a massive engine used in mining haul trucks and marine applications. This bench is critical for maintaining fleet uptime.

• Technical Training Schools: An excellent teaching aid for diesel technology students to understand the mechanics and software behind HPI fuel systems.

FAQ

Q1: What specific components can the BC-X15Q60 test?
A: This machine is specially designed to test the flow and pressure of HPI actuators. It is perfectly suited for testing the CUMMINS HPI ISX, ISX15, QSX15, and QSK60 Engine Diesel Fuel Pump Metering Control and Timing Actuators.

Q2: What are the electrical power requirements for this test bench?
A: The equipment is highly adaptable and can be wired for 380V (3-phase), 220V (3-phase), or 220V (single phase). Please ensure the power cord is properly grounded. If your facility's voltage fluctuates, using a power voltage stabilizer is strictly advised.

Q3: Can I test actuators if the power supply is unstable?
A: It is not recommended. Precision electronic instruments control the testing process. Unstable voltage can cause the screen to flicker or interrupt the program. Always use a voltage regulator if your power grid is not stable.

Q4: Does the machine come with testing software?
A: Yes, the BC-X15Q60 includes a built-in "System Test Bench" operating interface. The software clearly separates "Metering" and "Timing" tests, displaying real-time data such as pulse width (μs), frequency, and drive curves.

Q5: What should I avoid when operating the machine?
