CR1017 Multi-Function Diesel Test Bench_CRI CRP EUI EUP HEUI All-in-One Tester

One Machine, All Systems: Unveiling the CR1017 Multi-Function Diesel Test Bench

In the rapidly evolving world of diesel engine maintenance, versatility is key. Beacon Machine Manufacturing Co., Ltd. introduces the CR1017 Series, a flagship line of test benches designed to handle the most complex diagnostic tasks. Whether you need to test Common Rail Injectors (CRI), Common Rail Pumps (CRP), or heavy-duty systems like EUI, EUP, and HEUI, the CR1017 is engineered to deliver precision and efficiency.

Why Choose the CR1017?

The CR1017 is not just a test bench; it is a comprehensive diagnostic station. It integrates pneumatic, electrical, and hydraulic systems to simulate real-world engine conditions. Here are the standout features based on our latest technical configurations:

1. Comprehensive Testing Capabilities
The CR1017 allows for the testing of a wide array of components on a single platform:

• Common Rail Injectors & Pumps: Fully supports Bosch, Denso, Delphi, Siemens, and CAT systems. It handles high-pressure testing up to 2400 bar (expandable to 2800 bar with CP4 pump upgrade).

• EUI/EUP Testing: Equipped with various cam boxes (TU-A/B/C/D/E) to test varying models including Caterpillar, Cummins, Volvo, and Detroit.

• HEUI System: Specifically designed to test CAT C7, C9, 3126B, and 3412E injectors, as well as Isuzu and Ford PowerStroke injectors.

• Specialized Functions: Includes testing for Cummins PT injectors, Cummins HPI Q60 X15, and Unit Pumps.


2. Intelligent Control System
The heart of the CR1017 is its advanced software:

• Massive Database: Pre-loaded with over 7,543 injector data files and 1,039 pump data files.

• Multi-Language Support: The interface supports 15 languages, including English, Spanish, Russian, French, and Portuguese, making it accessible globally.

• Coding Capabilities: Generates QR codes for Bosch, Denso, Delphi, and Siemens injectors to ensure seamless ECU integration.

• Remote Updates: The system supports online updates and remote assistance via TeamViewer.


3. Robust Hardware Specifications

• Motor Power: Standard configuration of 7.5KW (or 5.5KW) with a speed range of 0-4000 r/min.

• Precision Measurement: Uses high-accuracy flow sensors for injection and return oil measurement.

• Temperature Control: Automatic heating and cooling of testing oil (40±2°C) ensures data consistency.

• Durability: Features a double filtration system and a forced cooling system for the testing oil.

4. User-Friendly Design
The machine features a sleek design with dimensions of 86x100x180 cm and comes with a complete set of accessories, including high-pressure oil pipes, adaptors, and specialized fixtures for different injector types.

For more details on the CR1017 or to request a quote, visit our official websites: www.beaconmachine.com

6. Application Scenarios & FAQ

Application Scenarios

1. Professional Diesel Repair Workshops: A single station to handle diverse customer needs, from passenger cars (CR systems) to heavy trucks and machinery (EUI/HEUI systems).

2. Pump and Injector Remanufacturing: Essential for "End of Line" testing to verify rebuilt parts against OEM specifications before sale.

3. Fleet Maintenance Centers: Ideal for logistics companies or construction firms managing mixed fleets of trucks and excavators (e.g., CAT, Volvo, Cummins engines).

4. Technical Training Institutes: Used for teaching students the principles of modern diesel electronic control systems.

FAQ

Q1: What brands of injectors can the CR1017 test?
A: It supports all major brands including Bosch, Denso, Delphi, Siemens, CAT, and Cummins. It covers both solenoid and piezo injectors.

Q2: Does the machine come with the necessary cam boxes for EUI/EUP testing?
A: Yes, depending on your configuration requirements, we can equip the machine with TU-A, TU-B, TU-C, TU-D, and TU-E cam boxes to cover a wide range of engines like Volvo, CAT, and Cummins.

Q3: Can I update the test data?
A: Absolutely. The software supports online updates. As new injector data becomes available, your system can be updated to stay current.

Q4: What is the warranty period?
A: We offer a one-year warranty. Additionally, we provide lifetime technical support. If non-human damage occurs within one year, accessories are replaced free of charge.

Q5: What power supply is required?
A: The standard configuration is 3-phase 380V, but we also support single-phase 220V depending on your local power grid requirements.

Q6: Can it print test reports?
A: Yes, the system generates detailed test reports which can be printed. You can also customize the report with your own company logo.
